HIsmelt SRV Smelt Reduction Vessel

SRV Furnace  (Smelt Reduction Vessel)
SRV furnace is Key equipment to smelt and reduce iron in whole HIsmelt technology. The equipment includes a cylinder, a cooling wall in slag zone and a precell. The cylinder contains furnace and the gas chamber. The diameter of the straight segment is Φ 9280 mm and the gas diameter chamber is Φ 5260.

Application

 The SRV furnace tranformsiron ore into molten cast iron water with the injection of pulverized coal, air, steam and iron ore. The slag area cooler of the SRV furnace can enhance cooling intensity, promote slag formation, effectively protect the refractory material. Refractory material can broaden the range of slag composition, lower the standards of MgO content in the slag, and increase service life of the refractory material at the same time reduce the equipment cost.

Features

01.With high safety, and through comprehensive security measures to ensure the safety of the equipment and personnel. Equipped with interlock control system to reduce accidents caused by manual misoperation; Equipped with power emergency system to avoid the damage to the equipment when power cut or other extreme cases; Equipped with video monitoring system to observe the production condition for operators and reduce accidents.

02.With high reliability, and through the use of advanced design means to ensure reliability and durability of the equipment. The use of advanced design and analysis method to optimize the product design and ensure the reasonablity of the product structure; To ensure the reliability of every aspect of the product; Selecting high quality material to ensure the product quality, prolong service life and reduce equipment wear and tear.
